10.4" 觸控電腦 (intel N3350/4200)
工業平板電腦
產品規格
Model name | 10.4" Touch PC (intel N3350/4200) | |
---|---|---|
CPU | Intel® Celeron/Pentium Processor | |
Memory | DDR3 SO-DIMM 8G | |
Storage | SATAx1, M.2 M-key (SATA 6Gb/s) x1, Full-size Mini PCIe Slot x1 | |
GPU Chip | Intel® HD Graphics 500 | |
Sound Chip | Realtek® Audio CODEC | |
Network | Intel® i211AT Gbe LAN Chips x2 | |
Panel Process | IAV Mode, Normally Black | |
Display Size | 10.4 inch | |
Visible Area | 210.4x157.8 mm | |
Resolution | 1024x768 (XGA) | |
Color Depth | 16.2M Colors | |
Brightness (nits) | 500 / (Optional) 1000 / (Optional) 1500 nits | |
Contrast Ratio | 1000:1 | |
Display Ratio | 4:3 | |
Pixel Pitch | 0.0685x0.2055 mm | |
Response Time | 25 msec. | |
Viewing Angle | 176°/176° | |
Backlight | LED(white LED) | |
min. Panel lifetime | >50,000 HRS | |
Operating Temp. | -30°~85°C | |
Storage Temp. | -30°~85°C | |
Touch Technology | Projected Capacitive | |
Allowed Touch Points | 10 points | |
Thickness of Cover Lens | 1.8±0.2mm | |
Hardness of Cover Lens | 7H | |
Accuracy | 99.00% | |
Transparency | ≥ 87% | |
IK Ratings | IK07 | |
產品描述
10.4 吋工控等級面板, 1024×768 解析度
★ IAV 廣視角製程, 176°/176°
★ 廣溫液晶製程, 耐受溫度-30~85 度
★ Intel® Quad-Core N3350/N4200 CPU
★ DDR3 8G DRAM
★ 窄邊框全平面投射式電容觸控,強化玻璃硬度7H
★ 10 點觸控,支援原鑫專用觸控筆
★ 金屬外殼,搭配多樣化的安裝支架選項
★ 台灣製造,三年保固,適用各種嚴苛環境
★ 最大亮度可達1500nits (選配)
★ 抗眩光/防窺/抗菌膜等表面處理 (選配)
